ASTM A533 Grade A Low Alloy Steel , A533 Grade A steel plate

Posted:2015-12-03 01:59:24

ASTM A533-A steel is a kind of material for boiler and pressure vessel steel, We can supply coils,plates,sheets in stock and arrange production for you specially.A533GrA,A533GrB,A533GrC and A533GrD.They are often used in the beltline region of nuclear reactor vessels where the material properties may be affected by high levels of radiation.

The following is their chemical composition About ASTM A533-A steel, we can offer the following A533-A steel plate specification:

Standard : ASTM A-533/A-533M

Steel Grade : A533 Gr A, A533 Gr B, A533 Gr C, A533 Gr D

Maximum Thickness: 300mm Width: 1500mm to 4020mm Length: 3000mm to 18000mm

Chemical Composition and Mechanical Property:

Grade

Chemical Composition(%)

C

Mn≥

Si

P

S

A533 Grade A

(A533GR A)

0.25

0.13-0.45

1.07-1.62

0.035

0.035

Grade

Mechanical Property

Tensile Strength(MPa)

Yield Strength(MPa)

% Elongation in 2 in.(50mm) min

Impacting Test Temperature(°C)

A533 Grade A

(A533GR A)

470-630

345

20

20

we can supply high quality carbon steel plate for boiler and pressure vessel fabrication which is ideally suited to the high standards set by the oil, gas and petrochemical industry -If you need any kinds of steel plate,steel coils or others products,please contact us for more information by email or leave a message for us ,we will give you the best service and price!
