ASTM A387 GRADE 11 CLASS 1,SA387GR11CL1 Pressure Vessel And Boiler Steel Plate

Posted:2015-12-16 22:39:44

SA387 Grade 11 Class 1 is in the standard ASME SA-387/SA-387M .SA387GR11CL1 Pressure Vessel And Boiler Steel Plate are used in Pressure Vessel,Boiler,Storage Tanks and Heat Exchanger in Oil,Gas Project.

we are specialized in supplying ASTM steel plate in A387 Grade11 Class1.for more information about ASTM A387 GRADE 11 CLASS 1,please check them in following:

Standard: ASME SA-387/SA-387M

Steel Grade : SA387 Grade 11 Class 1

Dimension range we mainly supply:1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm

Chemical Composition and Mechanical Property:

Grade

Chemical Composition(%)

C

Mn≥

Si

P

S

SA387 Grade 11 Class1(SA387GR11CL1)

0.04-0.17

0.35-0.73

0.44-0.86

0.035

0.035

Grade

Mechanical Property

Tensile Strength(MPa)

Yield Strength(MPa)

% Elongation in 2 in.(50mm) min

Impacting Test Temperature(°C)

SA387 Grade 11 Class1(SA387GR11CL1)

415-585

240

22

-20,40,-60

ASME SA387 Grade 11 class 1 pressure vessel steel is widely used in petroleum, chemical industry, power station, boiler, etc,used to make the reactor, heat exchanger, separator, spherical tank, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station, high pressure pipe.

If you need more stock steel plates in ASTM A387 GRADE 11 CLASS 1,please contact us for more information about price and others,we can give you the best service!
