ASME SA203 Grade D|SA203 Gr.D STEEL PLATE

Posted:2015-12-07 02:32:27

SA203 Grade D steel grade is a nickel alloy steel plate in welded pressure vessels.SA203 Grade D is used in fabricators serving industry, especially in the oil, gas and chemical supply markets. we have much experience exporting boiler plate in SA203 Gr.D to factory mill many years.

Steel Grade:SA203 Grade D Steel Standard: ASME SA203/SA203M

Thickness:6mm-450mm Width:1200mm-4200mm

Length:3000mm-18000mm Surface Treatment:Shot blasting and painting or coated

SA203 Grade D steel plate, in yield of 255Mpa , Tensile in 450Mpa. In fact, The SA203 Gr.A and SA203 Gr.D are the same in mechanical property. But the SA203 Gr.D nickel is 3.25% , A 203 Gr. A nickel 2.25%.

SA203 Grade D Chemical Composition
Grade The Element Max (%)
C Si Mn P S
SA203 Grade D 0.17 0.13-0.45 0.70-0.80 0.035 0.035


Mechanical Property of SA203 Grade D steel plate SA203 Grade D
Tensile strength, kis [MPa] 65-85 [450-585]
Yield strength, min, kis [MPa] 37 [255]
Elongation in 8 in. [200 mm], min, % 19
Elongation in 2 in. [50 mm], min, % 23

If you need more stock SA203 steel plates in pressure vessel steel plate, please contact us by email or calling.
